Yaskawa PG-X2 Elevator Speed Control Card

PG speed controller card, PG-X2 is mounted on the control board of the inverter,and performs speed feedback using the pulse generator (PG) on the motor to correct speed fluctuations caused by slipping. Motor rotation direction is detectedby phase A and phase B PG pulse inputs. The card is used for flux vector control.

Applicable to RS-422 output PG
Phase A and phase B pulse (2phase pulse)inputs for vector control
Maximum input frequencyrange : 50 to300kHz
Pulse monitor output : RS-422 output
